米国時間 12/04付けでリリースされました。
Linux Redhat7.2用ファイルはCUDAバージョンにより2個用意されています。
- T3DDistrib_Rev357_191204_RHEL7.2_Intel.tar.gz : CUDA 10.0以上用
- T3DDistrib_Rev357_191204_RHEL7.2_Intel_Cuda9.1.tar.gz : CUDA 9.1用
自分のマシンのCUDAバージョンは、nvidia-smi コマンドで確認できます。
%nvidia-smi
+-----------------------------------------------------------------------------+
| NVIDIA-SMI 410.78 Driver Version: 410.78 CUDA Version: 10.0 |
|-------------------------------+----------------------+----------------------+
| GPU Name Persistence-M| Bus-Id Disp.A | Volatile Uncorr. ECC |
| Fan Temp Perf Pwr:Usage/Cap| Memory-Usage | GPU-Util Compute M. |
以下リリースノートです。
Rev: 357
Author: sandeep
Last modification:Rev 357 – 2019-12-05 11:56:17 -0500 (Thu, 05 Dec 2019)
Log message: 2019/12/05
==========
1) Fixed bug in SEARCHSTRESS menu–incorrect tooth numbers
were being shown on the legend when AUTOTOOTH option was checked.
2) The values for Raleigh alpha, beta, density and thermal
expansion coefficient were not being initialized when a
.spa file was loaded.
3) Updated the RearAxle models: the housing models were missing
density numbers.
4) Updated kip file reader to correctly read left-handed face-milled
gear machine settings.
5) Improved the mesh layout for a shaft segment with axial holes.
6) Added a new flag AUTOBASECONE in the BEVEL|TOOTH menu to
auto-calculate base cone of bevel gears.
7) Added a new flag called SPECIFYOUTERDIADISTANCE in the
BEVEL|TOOTH menu to specify the location
of the OUTERDIAMETER on the back cone of bevel gear.
8) Added “Write to PowerPoint” option to Guide. This will
only be enabled if PowerPoint is installed on the system.
This feature will export selected graphics pages to
a new PowerPoint pptx file.
9) Added new python callable functions to the multyxdll interface
in the python scripts in the Scripts folder. The new functions
allow you to set/query variables which might be integer, boolean,
switches, or strings.
10) Bug fix: Guide was crashing for one case when names of
surface pairs were too long.
11) Bug fix: Imported FE meshes for planetary pin-shaft segments
and pinion-shaft segments were not being connected correctly
to adjacent segments.
12) Bug fix: when an imported housing model consists of
multiple files, the DELTA_TEMPERATURE value was not being
applied correctly, iSys was not routing changes to it correctly.
13) Bug Fix: There was a typo in the sample pythonscript in
SAMPLES/OptimizeTEHelicalPair/OptimizeTE.py. The typo was
causing a python error.
